ROLLS DIVISION
ALLOY CAST STEEL ROLLS
Microstructure of Alloy
cast steel rolls
Distance from surface - mm
Hardness - ShC
CHARACTERISTICS
Carbon content in Alloy Cast Steel Rolls is in the range of 0.50% to 0.80%. These hypo-eutectoid steel rolls are alloyed with Chromium and Molybdenum. The heat treatment of these rolls involves double annealing cycles followed by tempering. This helps to improve toughness and thermal shock resistance. The microstructure is primarily fine pearlitic with broken/spheroidized cementite. These rolls have high mechanical strength with good weldability.
SUPPLY CONDITIONS
- CO2 PROCESS
- PROOF MACHINED
- FINAL SIZE MACHINED/ BEARING SIZE
- HEAT TREATMENT
- GRADE CONFIRMATION tdROUGH SPECTROMETER AND UTM MACHINE
CHEMICAL COMPOSITION
| C% | MN% | SI% | P% | S% | NI% | CR% | MO% |
| 0.80 | 0.60 | 0.30 | 0.05 | 0.05 | 0.50 | 0.80 | 0.25 |
| 2.00 | 1.20 | 0.80 | MAX | MAX | 1.30 | 1.60 | 0.60 |
APPLICATIONS
These rolls are ideally suited for Blooming Mills and Roughing Stands for Light and Heavy Section Mills
